Single-Phase Seismic Inverter
Delivering up to 98% efficiency and available in sizes from 1.5 to 16.7 kVA, the E-H Series is an OSHPD-rated central inverter family designed to provide reliable, code-compliant backup power for lighting and motor load applications in healthcare facilities and other seismically sensitive environments. Featuring shaker table-tested seismic performance, a space-saving single-cabinet design, ultra-fast 2 ms transfer time, NFPA 101 self-testing and data logging, and advanced monitoring and communications options, the E-H Series combines dependable operation, regulatory compliance, and simplified system management in a compact footprint
Indoor / Outdoor: Indoor
Seismic-Rated: Yes
Mounting Options: Floor-Mount
Phase: Single Phase
Power Rating: 1.0-5.0 kVA | 5.0-10.0 kVA | 10.0-25.0 kVA
Input Voltage: 120 VAC | 208 VAC | 240 VAC | 277 VAC | Custom
Output Voltage: 120 VAC | 120/277 VAC | 120/208 VAC | 120/240 VAC | 277 VAC | 277/120 VAC | Custom
Run Time: 90 Minutes | 120 Minutes | Configurable
Compliance: OSHPD | NFPA 101 | UL 924 | BAA | BABA | TAA
Connectivity: IoT Inverter Connect | BACnet | BACnet IP | Modbus TCP/IP | Modbus RTU | RS-232 | SEA
Battery Type: Valve Regulated Lead-Acid (VRLA)
Features & Options: Remote Summary Alarm Panel | Battery Thermal Management | Fast Charge | 5-Year Service Plan | Extended Warranty | Startup Service
Applications / Loads: Emergency Lighting | Healthcare | Education | Commercial/Retail | Data Centers
